Vertical Frame Tube

Jiangsu Xinhuasheng Packaging New Materials Co., Ltd. is one of the leading manufacturers and suppliers of vertical frame tube in China. We are committed to provide high quality customized products made in China with low price. Welcome to buy discount vertical frame tube in stock here and get free sample from our factory.

Vertical Frame Tube, a critical vertical structural component within an Intermediate Bulk Container (IBC) or tote tank frame, serves as the primary load-bearing column. It is engineered to provide essential structural integrity, stability, and support for the entire container assembly, ensuring safe handling, stacking, and transportation of liquids and semi-solids in industrial settings. ‌

Core Structural Support
Acts as the main vertical support, connecting horizontal tubes, crossbeams, and the base structure to form a rigid and stable frame.



High Load-Bearing Capacity
Designed to withstand both vertical loads (stacking pressure) and lateral forces during handling and transport.



Anti-Deformation Performance
Maintains the shape of the IBC tank and prevents distortion under heavy loads or long-term use.



Durable & Corrosion-Resistant
Made from high-quality steel with galvanized or coated surface treatment for excellent resistance to rust and harsh environments.



Secure Frame Integration
Precisely engineered for strong connections with other frame components, ensuring overall structural stability.

Load Transfer Path:

• During Stacking: The weight from the upper IBC tank's bottom feet → transfers to the top frame of the lower tank → then to the vertical frame tubes → down to the bottom pallet → and finally to the ground. In this process, the vertical steel tubes mainly bear axial compression.
• During Handling: When a forklift accidentally impacts the side of the IBC tank, the vertical steel tubes act as the outermost structural support. Their rigidity and toughness absorb impact energy, preventing the inner container from being punctured.

Inner Container Fixation: The vertical frame tubes, together with the top pressing structure (such as compression bars or mesh) and bottom corner protectors, clamp the HDPE inner container vertically, preventing it from moving up and down during transportation vibrations.

The strength and quantity of vertical frame tubes determine the suitability of IBC tanks for different scenarios:

• General Chemical Industry: A standard structure with four vertical columns is sufficient for transporting water or low-density chemicals.
• Heavy Industry: For high-density liquids, reinforced frames with thicker wall steel tubes or additional vertical columns are required to prevent deformation during stacking.
• Export & Ocean Freight: During sea transport, containers are subject to movement and compression, so the welding quality of vertical steel tubes must withstand strong dynamic loads.

‌
